Description

The Club is the only Ortofon DJ cartridge to feature a special elliptical stylus that fits better in the record groove, allowing for more contact with the groove itself. This results in a richer, more detailed sound than can be achieved with a spherical stylus.

The new stylus body design makes it easier to see the groove with a wider stylus-view cut-out. Tactile feedback when mounting the stylus tip to the body gives an added layer of security. The new, textured finger grip gives you a wider area to hold on to and is now replaceable, making the new Concorde even tougher in demanding environments.

The Club is also recommended for DJs looking to digitize their vinyl collection due to its clarity and quality of sound reproduction.

Technical Data

Output Voltage (@ 1kHz, 5cm/sec.): 8mV
Channel Balance (@ 1kHz): 1dB
Channel Separation (@ 1kHz): 25dB
Channel Separation (@ 15kHz): 15dB
Frequency Range (@ -3dB): 20 – 20,000Hz
Tracking Ability (@ 315Hz)*: 100μm
Compliance (Dynamic Lateral): 14μm / mN
Stylus Type: Spherical
Stylus Tip Radius (R): 18μm
Tracking Force Range: 2.0 – 4.0g (30 – 50mN)
Recommended Tracking Force: 3.0g (40mN)
Cartridge Weight: 18.5g
Replacement Stylus Unit: Club


* At recommended tracking force
