Description

It’s spherical stylus is suitable for both mixing and back-cueing and the new design makes it easier to see the groove with a wider stylus-view cut-out. Tactile feedback when mounting the stylus tip to the body gives an added layer of security.

The new, textured finger grip gives you a wider area to hold on to and is now replaceable, making the new Concorde even tougher in demanding environments.

The Mix’s high sound quality and tracking ability make it suitable for virtually any type of music and DJ.

Technical Data

Output Voltage (@ 1kHz, 5cm/sec.): 6mV
Channel Balance (@ 1kHz): 1.5dB
Channel Separation (@ 1kHz): 20dB
Channel Separation (@ 15kHz): 15dB
Frequency Range (@ -3dB): 20 – 20,000Hz
Tracking Ability (@ 315Hz)*: 100μm
Compliance (Dynamic Lateral): 14μm / mN
Stylus Type: Spherical
Stylus Tip Radius (R): 18μm
Tracking Force Range: 2.0 – 4.0g (30 – 50mN)
Recommended Tracking Force: 3.0g (40mN)
Cartridge Weight: 18.5g
Replacement Stylus Unit: Mix


* At recommended tracking force
