Description

TRK PRO2

24-BIT 192kHz USB AUDIO INTERFACE

  • 2 In 2 Out USB 2.0 Bus-Powered Audio Interface
  • Zero-latency monitoring
  • Perfect for RDNet Measures
  • Rack Mount Ears included

FEATURES

  • 2 In 2 Out USB 2.0 Bus-Powered Audio Interface
  • Up to 24-Bit/192kHz
  • 2 Mic and Instrument/Line Combo input
  • High-Quality Preamps
  • Balanced Output
  • Independent Headphone Volume Control
  • Zero-latency monitoring
  • Independent Gain Control with Signal-Peak LED
  • Perfect for RDNet Measures
  • Rack Mount Ears included

RCF TRK PRO2 hardware interface packs a robust and well-thought USB 2.0 studio-in-a-box with all the connectivity required for microphones, musical instruments, or line-level signals to a computer running macOS or Windows. The 2-channel internal linear preamp circuit allows the connection of 48V phantom-powered microphones and Hi-Z level instruments. Input signals can be routed to DAW (Digital Audio Workstation) at up to 24-bit, 192 kHz resolution; similarly, software monitoring and direct monitoring can be routed to the balanced outputs with variable mixing ratio. The interface can be connected to an amplifier and speakers, powered monitors, headphones, an analog mixer, or other analog audio devices.

Experience RCF in your studio

RCF packs 70+ years of experience in pro audio into your studio. Musicians and creators can now rely on the new TRK PRO Series to record and listen with amazing detail, anywhere. A robust and well-thought USB 2.0 studio-in-a-box with all the connectivity required for your microphones, guitars, keyboards, or any other audio device.

The Right Sound for Your Story

Whether it’s a podcast, a vlog, or a voiceover you’re creating, TRK PRO gives you everything you need. Record speech in high quality and edit through your headphones or your stereo monitors with remarkable reliability.

SPECIFICATIONS

GENERAL SPECIFICATIONS
MIC INPUT 1/2 (Balanced)
Freq. Response: 20Hz-20kHz, +/-0.1dB
THD+N: <0.0011%, -1dBFS, 20Hz-20kHz
Noise EIN: < -120dB
Dynamic Range: 107dB (A-weighted)
Input Impedance: 3.5KOhm
Gain Range: -9 dB ~ +47 dB
Maximum Input Level: +9 dBu
LINE INPUT 1/2 (Balanced)
Freq. Response: 20Hz-20kHz, +/-0.1dB
THD+N <0.0011%, -1dBFS, 20Hz ~ 20kHz
Dynamic Range: 107 dB (A-weighted)
Input Impedance: 15 kOhm
Gain Range: -20 dB ~ +36 dB
Maximum Input Level: +20 dB
INSTRUMENT INPUT 1/2 (Unbalanced)
Freq.Response: 20Hz-20kHz,+/-0.1dB
THD+N: <0.0025%,-1dBFS,20Hz-20k
Input Impedance:1MOhm
Gain Range: -10 dB ~+46 dB
Maximum Input Level: +10 dBu
Dynamic Range: 107 dB (A-weighted)
ANALOG OUTPUT (Balanced)
Maximum Output Level 0dBFS=12dBu
Freq.Response: 20 Hz~20 kHz,+/-0.2
THD+N: <0.0012%, -1dBFS, 20Hz-20 kHz
Dynamic range: 107 dB (A-weighted)
HEADPHONES OUTPUT (Unbalanced)
Output Impedance: <10 Ohm
Max Output Level: 500 Ohm – 114 mW
SUPPORTED SAMPLE RATES
44.1 kHz, 48 kHz,
88.2 kHz,96 kHz,
176.4 kHz, 192 kHz
SUPPORTED BIT DEPTH
16 Bit, 24 Bit
STANDARD COMPLIANCE
Safety agency: CE compliant
PHYSICAL SPECIFICATIONS
Cabinet/Case Material: Steel
Hardware: Rack mount ears incuded
Color: Black – RAL 9005
Rack mounting: 1/2 19″, 1U
SIZE
Height: 46 mm / 1.81 inches
Width: 210 mm / 8.27 inches
Depth: 125.8 mm / 4.95 inches
Weight: 0.85 kg / 1.87 lbs
