Description

Wash FX Hex

Brilliance, brightness and versatility are packed inside this powerhouse multi-purpose effect light that packs a punch with hex color (RGBAW+UV) LEDs. Wash FX Hex functions as a chase effect, blinder, or a wash light. 6 chasing zones mean Wash FX Hex can be used as a regular wash light or eye-candy effect and an advanced master/slave feature that allows you to mirror effects between units. Multiple control options include stand-alone mode, DMX, and IR as Wash FX Hex is compatible with an optional IRC-6 wireless remote for wireless triggering. Power linking saves time running cables.

Highlights

  • Multi-purpose effect light functions as chase effect, blinder, or a wash light
  • Generate a broad spectrum of colors and achieve natural-looking color temperatures with Hex color LEDs
  • Advanced master/slave feature allows you to mirror effect between units
  • Use as a regular wash light or eye-candy effect with 6 chasing zones
  • Multiple control options include stand-alone, DMX, IR, or master/slave
  • Compatible with the IRC6 wireless remote for wireless triggering
  • Power linking saves time running cables

Specifications

  • DMX Channels: 3, 6, 11 or 40
  • DMX Connectors: 3-pin XLR
  • Light Source: 18 LEDs (hex-color RGBAW+UV) 8 W, 2.8 A, 50,000 hours life expectancy
  • Strobe Rate: 0 to 24 Hz
  • Beam Angle: 41°
  • Field Angle: 68°
  • Illuminance: 2,422 lux @ 2 m
  • Power Linking: 3 units @ 120 V; 5 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 200 W, 2.5 A @ 120 V, 60 Hz
    194 W, 1.5 A @ 230 V, 50 Hz
  • Weight: 7.0 lbs (3.2 kg)
  • Size: 11.2 x 6.3 x 13 in (285 x 160x 330 mm)
  • Approvals: CE
  • Optional Controllers: IRC-6
  • Wavelength: 380 to 400 nm

WHAT’S INCLUDED

  • Wash FX Hex
  • Power Cable
  • Quick Reference Guide
